Product Details
Shakespeare VHF Radio Antenna Classic Sailboat 5216
The Shakespeare 5216 VHF Antenna is 15 inches long with unity gain. It is also a popular, basic antenna designed to reduce signal fading in rough seas.
Features:
- End-fed center-loaded stainless steel whip antenna with gold-plated connector
- Brass and copper elements for maximum range and efficiency
- Specifically designed and built for racing sailboats
- 2-year limited warranty
Specifications:
-
- Shakespeare Model No. 5216
- Length: 15"
- Sections: 1
- Color: Black
- Ferrule: L-bracket
- Cable Supplied: None (sold separately)
- Connector Supplied: SO-239 (PL-259 sold separately)
- Band: VHF Marine Band
- Gain: Unity
- Max. Input Power: 25W
- SWR (Standing Wave Ratio): Nominally 1.5:1 at 156.8 MHz
- Bandwidth: 5 MHz within 2.0:1 VSWR
- Impedance: 50 ohm
- Polarity: Vertical
- DC Ground: No
VHF Radio Antenna; Classic Series; For Use With VHF Marine Radio; Monopole; 15 Inch Length; Unity Gain; Mast Mount On Sailboat; Black; With Chrome Plated Brass Ferrule/ SO-239 UHF Female Connector And L Bracket
