Product Details
Shakespeare VHF Radio Antenna Classic Whip 5215
The Shakespeare 5215 Squatty Body VHF Antenna is 3 feet long 3db gain and is a lightweight, low-profile, 316 stainless steel antenna with L-Shaped Bracket and Retaining Hex Nut
Features:
- End-fed 1/2-wave stainless steel whip
- Tin-plated copper wire coil
- Supplied with stainless steel L-shaped mounting bracket
- 2-year limited warranty
Specifications:
- Shakespeare Model No.5215
- Length: 3'
- Sections: 1
- Color: Stainless steel /white
- Ferrule: L-shaped bracket and Retaining Hex Nut
- Cable Supplied: None (sold separately)
- Connector Supplied: SO-239 female connector (PL-259 male connector sold separately)
- Band: VHF Marine Band
- Gain: 3 dB
- Max. Input Power: 50W
- SWR (Standing Wave Ratio): Nominally 1.5:1 at 156.8 MHz
- Bandwidth: 7 MHz within 2.0:1 VSWR
- Impedance: 50 Ohms
- Polarity: Vertical
- DC Ground: No
Antenna will read as open when tested with ohm meter.
