Product Details
Shakespeare VHF Radio Antenna Classic Sailboat 5215-C-X
The Shakespeare 5215-C-X Squatty Body VHF Antenna is a 3ft 3db gain lightweight low-profile 316 stainless steel antenna is expressly designed for mounting on a sailboat mast.
Features:
- End-fed 1/2-wave stainless steel whip
- Tin-plated copper wire coil
- Supplied with stainless steel L-shaped mounting bracket
- 2-year limited warranty
Specifications:
- Model No.5215
- Length: 3'
- Sections: 1
- Color: white
- Finish: Stainless steel
- Ferrule: L-shaped bracket and retaining nut
- Cable Supplied: 60' RG-8/X Cable
- Connector Supplied: (2) PL-259
- Band: VHF Marine Band
- Gain: 3 dB
- Max. Input Power: 50W
- SWR (Standing Wave Ratio): Nominally 1.5:1 at 156.8 MHz
- Bandwidth: 7 MHz within 2.0:1 VSWR
- Impedance: 50 ohm
- Polarity: Vertical
- DC Ground: No
