Shakespeare 8’ Galaxy® VHF Antenna 5225-XT 6dB White

Shakespeare has redesigned their original Model 5225-XT 8' (95") VHF Antenna, shortening it to 93" to help reduce shipping costs—without sacrificing performance. The updated Model 5225-XT-RL delivers the same high-quality specifications and reliability as the original, simply in a slightly more compact size.

Features

• Iconic Galaxy® style 5225 with a stronger, stiffer radome for durability

• Collinear-phased 5/8-wave elements for superior signal clarity

• Perfect for hard tops, T-tops, radar arches, or areas exposed to high winds and speeds

• Brass and copper elements for maximum range and efficiency

• Backed by a 5-year limited warranty

Specifications

• Model: Shakespeare 5225-XT-RL

• Comparable To: Galaxy® style 5223 CB antenna

• Length: 93"

• Sections: 1

• Color: Galaxy white

• Finish: High-gloss, non-yellowing polyurethane

• Ferrule: Stainless steel with standard 1"-14 thread

• Cable Included: 20' RG-8/X

• Connector Included: PL-259 (not pre-installed)

• Suggested Mounts: Shakespeare 4187 or 5187 (sold separately)

• Band: VHF Marine Band

• Frequency Range: 156 – 164 MHz

• Gain: 6 dB

• Max Input Power: 100W

• SWR: Nominally 1.5:1 at 156.8 MHz

• Bandwidth: 3 MHz within 2.0:1 VSWR

• Impedance: 50 ohm

• Polarity: Vertical

• DC Ground: Yes

Note: When tested with an ohm meter, this antenna will read as a short circuit.
