Shakespeare VHF Radio Antenna Classic Series 396-1
The Shakespeare 396-1 VHF Antenna is 5' long with 3db gain and is a popular, basic antenna designed to reduce signal fading in rough seas.
Features:
- Brass and copper elements for maximum range and efficiency
- The most widely used antenna on Coast Guard vessels
- 2-year limited warranty
Specifications:
- Shakespeare Model No. 396-1
- Length: 5'
- Sections: 1
- Color: White
- Ferrule: Chrome-plated brass with standard 1"-14 thread
- Cable Supplied: 15' RG-58
- Connector Supplied: PL-259 (not installed)
- Suggested Mount: Shakespeare 4187 or 58187 ratchet mounts (each sold separately)
- Band: VHF Marine Band
- Gain: 3 dB
- Max. Input Power: 50W
- SWR (Standing Wave Ratio): Nominally 1.5:1 at 156.8 MHz
- Bandwidth: 5 MHz within 2.0:1 VSWR
- Impedance: 50 ohm
- Polarity: Vertical
- DC Ground: No
Note: Antenna will read as "open" when tested with ohm meter.
