Shakespeare VHF Radio Antenna Classic Series 5101-BLK
The Shakespeare 5101 is an 8-ft, 6 dB gain VHF marine antenna built with brass and copper elements for exceptional signal clarity and durability. It features a chrome-plated brass ferrule, comes with 15 ft of RG-58 coax cable and a PL-259 connector, and is ideal for mounting in high, unobstructed locations. The 5101-BLK offers the same performance and features but with a sleek black finish for a modern look.
Key Features:
-
End-fed VHF marine antenna, 8 ft overall length, with matching stub
-
Brass and copper elements for reliable performance
-
Ferrule: chrome-plated brass
-
Includes 15 ft of RG-58 cable and a PL-259 connector
-
Suggested mounting options: Shakespeare Style 4187 or 5187 ratchet mount, or Style 410-R with 4008 extension
-
One-section design
-
Gain: 6 dB
-
Max input power: 50 W
-
Bandwidth: 5 MHz within 2.0:1 VSWR
-
SWR: ~1.5:1 at 156.8 MHz
-
Impedance: 50 Ω
-
DC ground: Yes — reads as “shorted” or “open” depending on model
-
Finish color: Black
-
Vertical polarization, omnidirectional pattern
-
2-year limited warranty
