Shakespeare VHF Radio Antenna Classic Series 5104-BLK
The Shakespeare 5104-BLK is a rugged 4-ft VHF marine antenna designed for reliable communication and lasting performance. Built with brass and copper elements, a chrome-plated brass ferrule, and a high-gloss black finish, it delivers 3 dB gain for clear reception on the water. Includes 15 ft of RG-58 coax cable and a PL-259 connector for easy installation.
Features:
-
Durable construction with brass and copper elements for reliable performance
-
Strong chrome-plated brass ferrule with standard 1″-14 thread ensures a secure mount
-
Comes with 15 ft of RG-58 coaxial cable and a PL-259 connector ready for installation (connector not pre-installed)
-
Single-section, smooth high-gloss polyurethane finish — resists yellowing over time for lasting aesthetics
-
Vertical polarization, one-piece design for straightforward setup
Specifications:
-
Length / Gain: 4 ft (1.2 m) with approximately 3 dB gain
-
Frequency Band: VHF Marine Band
-
Max Input Power: 50 W
-
SWR: Nominally 1.5:1 at 156.8 MHz; 5 MHz bandwidth within 2.0:1 VSWR
-
Impedance: 50 Ω
-
Warranty: 2-year limited warranty
- Compatibility: VHF Marine Radios
- Type: Monopole
- Length: 4 Feet
- Gain: 3 dB
- Mounting Type: Threaded Mount
- Color: Black
- Material: Brass/ Copper
- Smooth, Durable, High-Gloss White Or Fiberglass Finish Prevents Yellowing
- Brass And Copper Elements Provide Standard Range And Reception
- Chrome-Plated Brass Or Nylon Ferrule With Standard 1: -14 Thread Provides For Basic Install
- Easy To Install
- Limited 2 Year Warranty
